Laser Scanner System |
| Specifications: |
| Model |
SDL-SCS-002 |
SDL-SCS-003 |
| Response time |
0.2ms |
| Linearity |
+-2 % |
99.9% |
| scope |
¡À20¡ã |
| Average working current |
0.9A |
| Peak current |
5A |
| Coil resistance |
3¦¸¡À10% |
| Coil inductance |
180¦ÌH ¡À10% |
| Onload optic |
below 5mm light spot |
| Motor weight |
80g |
| Maximum scanning angle (mechanical angle) |
¡À15 degree |
¡À20 degree-30 |
| Working temperature |
0¡æ¡«40¡æ |
| Usage |
stage lighting, laser animation |
   |
|
|
| |
| Note: |
 |
See
the Glossary
and Technology
for information about the terms used |
|
In
the front of the laser, we add an infrared filter.
The residual IR part is less than 10-3. Please refer
to the
technology page for more information about the
filter. |
|
Other
Sytles and custom designs are available. Contact
us to discuss your needs. |
|
|
|
